一、制作Livy的parcel包和csd文件

1、配置java环境
需要java1.7以上，建议java1.8

2、配置maven环境
下载maven安装包，解压

wget https://dlcdn.apache.org/maven/maven-3/3.8.4/binaries/apache-maven-3.8.4-bin.tar.gz
tar zxf apache-maven-3.8.4-bin.tar.gz -C /data/build_livy_for_cdh6

配置环境变量

vim /etc/profile
    export MAVEN_HOME=/data/build_livy_for_cdh6/apache-maven-3.8.4
    export PATH=$PATH:$MAVEN_HOME/bin

source /etc/profile

3、下载 livy_zeppelin_cdh_csd_parcels

 cd /data/build_livy_for_cdh6
 yum install git -y
 git clone https://github.com/alexjbush/livy_zeppelin_cdh_csd_parcels.git

4、修改build脚本
主要是删除ZEPPELIN相关配置

cd livy_zeppelin_cdh_csd_parcels/
cat build.sh
#!/bin/bash
set -x
set -e

JAR_PATH=/data/build_livy_for_cdh6/livy_zeppelin_cdh_csd_parcels/apache-livy-0.7.0-incubating-bin.zip
DEST_PATH=/data/build_livy_for_cdh6/cloudera/livy_cdh_csd_parcels

LIVY_URL=http://apache.mirror.anlx.net/incubator/livy/0.7.0-incubating/apache-livy-0.7.0-incubating-bin.zip
LIVY_MD5="2c5b63757414af16da308e63749e1ae6"
LIVY_VERSION=0.7.0

livy_service_name="LIVY"
livy_service_name_lower="$( echo $livy_service_name | tr '[:upper:]' '[:lower:]' )"
livy_archive="$( basename $LIVY_URL )"
livy_folder="$( basename $livy_archive .zip )"
livy_parcel_folder="${livy_service_name}-${LIVY_VERSION}"
livy_parcel_name="$livy_parcel_folder-el7.parcel"
livy_built_folder="${livy_parcel_folder}_build"
livy_csd_build_folder="livy_csd_build"

function build_cm_ext {

  #Checkout if dir does not exist
  if [ ! -d cm_ext ]; then
    git clone https://github.com/cloudera/cm_ext.git
  fi
  if [ ! -f cm_ext/validator/target/validator.jar ]; then
    cd cm_ext
    git checkout "$CM_EXT_BRANCH"
    mvn package
    cd ..
  fi
}

function get_livy {
  if [ ! -f "$livy_archive" ]; then
    wget $LIVY_URL
  fi
  livy_md5="$( md5sum $livy_archive | cut -d' ' -f1 )"
  if [ "$livy_md5" != "$LIVY_MD5" ]; then
    echo ERROR: md5 of $livy_archive is not correct
    exit 1
  fi
  if [ ! -d "$livy_folder" ]; then
    unzip $livy_archive
  fi
}

function build_livy_parcel {
  if [ -f "$livy_built_folder/$livy_parcel_name" ] && [ -f "$livy_built_folder/manifest.json" ]; then
    return
  fi
  if [ ! -d $livy_parcel_folder ]; then
    get_livy
    mv $livy_folder $livy_parcel_folder
  fi
  cp -r livy-parcel-src/meta $livy_parcel_folder
  sed -i -e "s/%VERSION%/$LIVY_VERSION/" ./$livy_parcel_folder/meta/parcel.json
  sed -i -e "s/%SERVICENAME%/$livy_service_name/" ./$livy_parcel_folder/meta/parcel.json
  sed -i -e "s/%SERVICENAMELOWER%/$livy_service_name_lower/" ./$livy_parcel_folder/meta/parcel.json
  java -jar cm_ext/validator/target/validator.jar -d ./$livy_parcel_folder
  mkdir -p $livy_built_folder
  tar zcvhf ./$livy_built_folder/$livy_parcel_name $livy_parcel_folder --owner=root --group=root
  java -jar cm_ext/validator/target/validator.jar -f ./$livy_built_folder/$livy_parcel_name
  python cm_ext/make_manifest/make_manifest.py ./$livy_built_folder
}

function build_livy_csd {
  JARNAME=${livy_service_name}-${LIVY_VERSION}.jar
  if [ -f "$JARNAME" ]; then
    return
  fi
  rm -rf ${livy_csd_build_folder}
  cp -rf ./livy-csd-src ${livy_csd_build_folder}
  sed -i -e "s/%SERVICENAME%/$livy_service_name/" ${livy_csd_build_folder}/descriptor/service.sdl
  sed -i -e "s/%SERVICENAMELOWER%/$livy_service_name_lower/" ${livy_csd_build_folder}/descriptor/service.sdl
  sed -i -e "s/%SERVICENAMELOWER%/$livy_service_name_lower/" ${livy_csd_build_folder}/scripts/control.sh
  java -jar cm_ext/validator/target/validator.jar -s ${livy_csd_build_folder}/descriptor/service.sdl -l "SPARK_ON_YARN SPARK2_ON_YARN"

  jar -cvf ./$JARNAME -C ${livy_csd_build_folder} .
}

case $1 in
parcel)
  build_cm_ext
  build_livy_parcel
  ;;
csd)
  build_livy_csd
  ;;
*)
  echo "Usage: $0 [parcel|csd]"
  ;;
esac

5、编译脚本

sh build.sh parcel
sh build.sh csd

编译完成后，生成livy的parcel、manifest、csd文件

[root@node01 livy_zeppelin_cdh_csd_parcels]# ll LIVY-0.7.0_build/
total 90500
-rw-r--r-- 1 root root 92661923 Feb 15 16:09 LIVY-0.7.0-el7.parcel
-rw-r--r-- 1 root root      311 Feb 15 16:10 manifest.json
[root@node01 livy_zeppelin_cdh_csd_parcels]# ll LIVY-0.7.0.jar
-rw-r--r-- 1 root root 5608 Feb 15 16:10 LIVY-0.7.0.jar

6、修改parcel，添加livy用户和组

cd LIVY-0.7.0_build/
tar zxf LIVY-0.7.0-el7.parcel

cat LIVY-0.7.0/meta/parcel.json
# 修改groups和users，添加livy
{
  "schema_version": 1,
  "name": "LIVY",
  "version": "0.7.0",
  "setActiveSymlink": true,

  "provides": [
    "livy"
  ],

  "depends": "CDH",
  "replaces": "",
  "conflicts": "",

  "scripts": {
    "defines": "livy_env.sh"
  },
  "groups": ["livy"],
  "users": {
      "livy": {
          "extra_groups": [],
          "home": "/var/lib/livy",
          "longname": "LIVY",
          "shell": "/sbin/nologin"
      }
  },
  "packages": [],
  "components": []
}

rm -f LIVY-0.7.0-el7.parcel
tar zcf LIVY-0.7.0-el7.parcel LIVY-0.7.0

7、生成sha文件

echo -n $(sha1sum LIVY-0.7.0-el7.parcel | awk '{print $1}') > LIVY-0.7.0-el7.sha

二、CM添加Livy服务

1、拷贝csd文件
将制作出来的csd文件拷贝到cloudera里，并重启cloudera-scm-server

cp livy_0.7.0_cdh_parcel/csd/LIVY-0.7.0.jar /opt/cloudera/csd/
systemctl restart cloudera-scm-server

2、分配和激活parcel包
启动一个http服务提供parcel下载

cd livy_0.7.0_cdh_parcel/parcels
/opt/python3/bin/python3 -m http.server

访问cm界面，添加parcel配置

下载

分配

激活

3、配置hdfs core-site.html开启用户代理
在hdfs服务配置添加hadoop.proxyuser.livy.groups和hadoop.proxyuser.livy.hosts，并重启hdfs服务

4、添加Livy服务
在cm集群上，添加livy服务

5、修改Livy配置
根据情况修改livy的配置

三、验证Livy服务

1、创建交互式会话

curl -X POST -d '{"kind": "pyspark"}' -H "Content-Type: application/json" http://node04:8998/sessions

2、提交sql代码片段

curl http://node04:8998/sessions/0/statements -X POST -H 'Content-Type: application/json' -d '{"code":"show databases","kind":"sql"}'

3、查询结果

curl http://node04:8998/sessions/0/statements/0
{"id":0,"code":"show databases","state":"available","output":{"status":"ok","execution_count":0,"data":{"application/json":{"schema":{"type":"struct","fields":[{"name":"databaseName","type":"string","nullable":false,"metadata":{}}]},"data":[["default"],["dm_adm_db_dev"],["dm_ads_db_dev"],["dm_mdm_db_dev"],["dm_ods_db_dev"],["dm_pdm_db_dev"]]}}},"progress":1.0,"started":1644988250221,"completed":1644988253285}

查询结果正常，即Livy服务正常

4、删除会话

curl -X DELETE http://node04:8998/sessions/0

四、hue添加Livy+Spark

在cm上进入Hue服务界面，点击“配置”，在搜索栏输入“hue_safety_valve.ini”

添加配置如下：

[desktop]
app_blacklist=zookeeper,hbase,search,oozie,jobsub,pig,sqoop,security

[spark]
livy_server_host=node04
livy_server_port=8998
livy_server_session_kind=yarn

[notebook]
show_notebooks=true
enable_external_statements=true
enable_batch_execute=true
    [[interpreters]]
    # Define the name and how to connect and execute the language.

        [[[hive]]]
          # The name of the snippet.
          name=Hive
          # The backend connection to use to communicate with the server.
          interface=hiveserver2

        [[[impala]]]
          name=Impala
          interface=hiveserver2

        [[[sql]]]
          name=SparkSql
          interface=livy

        [[[spark]]]
          name=Spark
          interface=livy

        [[[pyspark]]]
          name=PySpark
          interface=livy

        [[[r]]]
          name=R
          interface=livy

        [[[jar]]]
          name=Spark Submit Jar
          interface=livy-batch

登录hue，点击“查询”->“编辑器”-> “Notebook”
注意：不要在这里直接选择SparkSql，经测试无法查询，Spark或者PySpark可直接在这里选择

在Notebook里选择SparkSql

执行一条Spark SQL语句
